Name: Long Lasting Metal Components With High Precision Chemical Etching Processing
Brand: Shenzhen Xinhaisen Technology Limited
SKU: XHS/ Customized
Price: 90.00 USD
Availability: InStock

Long Lasting Metal Components With High Precision Chemical Etching Processing

Brand Name:	XHS/ Customized
Model Number:	XHS/ Customized
MOQ:	10
Price:	80-100USD
Payment Terms:	T/T,Western Union
Supply Ability:	10000-100000PCS / week

Process of High Precision Chemical Etching:

Design Creation: A detailed CAD design is made to define the etching pattern.
Photoresist Application: A photoresist layer is applied to the metal surface.
Exposure & Development: The design is exposed to UV light and developed, transferring the pattern.
Etching: The metal is immersed in a chemical solution that etches away the exposed areas.
Cleaning: After etching, the component is thoroughly cleaned to remove any residue.
Inspection: The final product is inspected for precision, quality, and tolerance compliance.

Long Lasting Metal Components With High Precision Chemical Etching Processing 0

Applications of High Precision Chemical Etching:

Filtration: Micro filter meshes, screens, sieves, dust filter meshes, sugar screens, shower head filter meshes, smoke detector filter meshes, etc...
Electronics: Precision metal shims, washers, EMI/RFI shielding, lead frames, contacts, Spring, Flexures, etc.
Medical: Medical blades, precision shims, washers, implants, gaskets, medical device contacts, etc.
Automotive: Speaker mesh grilles, tread plates, Nameplates, Inlays, Fuel cell plates, Shims, gaskets, washers
Precision Engineering: Precision meshes, test sieves, screens, shims, gaskets, washers, Springs, Flexures, Diaphragms, Labels.
Aerospace & Defense: Connectors, brass contacts, Heat exchanges, EMI/RFI shields, Air intake grilles.

STEEL AND STAINLESS STEELS	0.01mm – 1.5mm	600mm x 1500mm
NICKEL AND NICKEL ALLOYS	0.01mm – 1.5mm	600mm x 1500mm
COPPER AND COPPER ALLOYS	0.01mm – 1.5mm	600mm x 1500mm
ALUMINIUM	0.01mm – 1.5mm	600mm x 1500mm
TITANIUM AND TITANIUM ALLOYS	0.01mm – 1mm	600mm x 550mm

Photo Chemical Etching

Stainless Steel Chemical Etching

Copper Chemical Etching

Titanium Etching

Nickel Etching

Aluminum Etching

Stamping Processing

Bipolar Plates Fuel Cell

Micro Perforated Mesh

Metal Speaker Grills

Encoder Discs

PCB Shielding Cans

Printed Circuit Heat Exchanger

Electrical Connectors

Custom Precision Components

Dermaroller Microneedle

Metal Shims

Photo Chemical Etching

Stainless Steel Chemical Etching

Copper Chemical Etching

Titanium Etching

Nickel Etching

Aluminum Etching

Stamping Processing

Bipolar Plates Fuel Cell

Micro Perforated Mesh

Metal Speaker Grills

Encoder Discs

PCB Shielding Cans

Printed Circuit Heat Exchanger

Electrical Connectors

Custom Precision Components

Dermaroller Microneedle

Metal Shims

products details

Long Lasting Metal Components With High Precision Chemical Etching Processing

Long Lasting Metal Components With High Precision Chemical Etching Processing

1.5mm metal components

0.02mm metal components

High precision metal parts

The material, thickness and size we can Chemical Etching:
