Xinhaisen specializes in manufacturing precision-etched dials for instrumentation, control systems, and industrial equipment. Our chemical etching process produces burr-free dials that outperform laser engraving or screen printing in longevity and clarity. Ideal for applications requiring precise readability under harsh conditions.

Manufacturing Process

Our watch dials are crafted using a controlled photochemical etching process:

• Design & Tooling: Your design is translated into a digital phototool. No hard physical tooling is required, enabling rapid and low-cost prototyping.

• Material Preparation: Selected metal sheets (e.g., stainless steel, brass, copper) are cleaned and laminated with a photosensitive resist.

• Exposure & Development: The phototool is used to UV-expose the resist, transferring the precise dial pattern. The unexposed resist is then developed away.

• Chemical Etching: The panel is etched in a controlled chemical bath, which dissolves the unprotected metal areas to create the design, textures, and openings.

• Stripping & Finishing: The remaining resist is stripped. The dials then undergo various finishing processes such as electroplating (gold, rose gold, ruthenium, etc.), brushing, sunray polishing, or PVD coating as per specification.

• Quality Inspection: Each dial is meticulously inspected for dimensional accuracy, surface finish, and cosmetic perfection.

Dials Features

• Burr-Free & Stress-Free: The etching process does not touch the material mechanically, guaranteeing perfectly smooth edges and no internal stress that could cause warping.

• High Complexity & Precision: Capable of producing extremely fine guilloché patterns, delicate logos, minute indices, and complex cut-outs that are difficult or impossible with stamping or machining.

• Ultra-Thin Profiles: Ideal for creating sleek, modern dials as the process does not compromise material integrity, even at very low thicknesses.

• Material Versatility: We can etch a wide range of metals suitable for watch dials, including various grades of stainless steel, brass, copper, nickel silver, and titanium.

• Fast Prototyping: Design changes can be made quickly and inexpensively by modifying the digital phototool, significantly accelerating your development cycle.

Dials Specification

Dials Applications

• Industrial Controls: Valves, pressure regulators
• Aerospace: Cockpit instrumentation
• Medical: Diagnostic equipment dials
• Transportation: Dashboard controls
• Energy: Pipeline monitoring gauges

Our Advantage for Watch Dials

• 13+ Years of Specialized Expertise: Pioneering developments in photochemical etching for high-tech markets ensure reliable, high-quality production.

• Internal Professional Team: Our in-house design and engineering team can cooperate with you to develop and optimize the dial design for manufacturability and aesthetics.

• Strict Quality Control: Equipped with a professional test lab and strict process control system, we adhere to high standards admired by the industry.

• Flexible Service: Capable of handling both bulk orders and customized small packaging, supporting various shipping terms (FOB, CIF, DDP).

FAQ

• Q: What file format do you need for the dial design?
  A: We prefer vector-based files such as .AI, .DXF, or .DWG with clear layer definitions.

• Q: Can you create a sunray or brushed finish?
  A: Yes, we offer a variety of finishing services, including sunray, vertical/horizontal brushing, electroplating, and PVD coating, as part of our post-etching processes.

• Q: What is the minimum order quantity (MOQ) for a custom dial?
  A: Our process is very flexible. We can support low MOQs for prototyping and scale efficiently to high-volume production runs.

• Q: How do you ensure consistency across a large production batch?
  A: Our advanced automatic machines and strictly controlled etching parameters ensure every dial in the batch is identical, with uniform etching depth and finish.
